Wylex 50A 30mA SPN B Curve 6kA Type A RCBO
Wylex 50A 30mA SPN B Curve 6kA Type A RCBO
Wylex 50A 30mA SPN B Curve 6kA Type A RCBO - Image 2
Wylex 50A 30mA SPN B Curve 6kA Type A RCBO - Image 3
Wylex 50A 30mA SPN B Curve 6kA Type A RCBO - Image 4

Wylex 50A 30mA SPN B Curve 6kA Type A RCBO

£44.75 Incl. VAT

Real contact position indicator. Push to test button. Single pole switching. High degree of touch protection IP20. · · · Single module, RCBO · · 50A B curve (MCB), 30mA Type A (RCD) · · Single pole · · Balcony terminal position · · Breaking Capacity 6 kA · · Sensitivity 30mA · · Mounting type Din rail · · IP20 · · AC leakage current type and B release characteristic

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: NHXSBS1B50 Categories: , , Brand: Product Code: 2500351656

Description

Technical Specifications  Technical Specifications Earth leakage circuit breaker/RCBO Tripping characteristic (type/curve) B Mounting method DIN rail Over voltage category 3 Number of poles (total) 2 Number of protected poles 1 Rated fault current 0.03 A Rated insulation voltage Ui 400 V Current limiting class 3 Width in number of modular spacings 1 Rated voltage 230 V Rated current 50 A Recess depth 74 mm Rated short-circuit breaking capacity Icn according to EN 61009-1 6 kA Rated impulse-withstand voltage (Uimp) 4 kV Connectable conductor cross section solid-core 0.75 – 16 mm² Connectable conductor cross section multi-wired 0.75 – 16 mm² Ambient temperature during operating -5 – 40 °C Concurrently switching N-neutral No Anti-nuisance tripping version No With interlocking device No · Technical Data Sheet – Click to Download
