Showing 25–33 of 33 resultsSorted by latest
-
CGD MCB 40A Single Pole B Curve 6kA (G06-1B40)
£3.01 Incl. VATOut of Stock
Designed to be used in our Steeple and Designa Curve consumer units, they are din rail mounted, designed to take a cable size from 1mm to 16mm and have a toggle with on/off indicator to switch the device on and off. This MCB provides protection against overloads, short circuits and infrequent switching of circuits under normal conditions. · · · Current Rating: 40A · · Rated short circuit capacity: 6kA · · Tripping Characteristic: B · · Terminal Tightening Torque: 2.5Nm · · Reference Standard: IEC / BS EN60898-5 · · Voltage 230V · · No. of modules: 1 x 18mm module · · Rated Frequency (Fn): 50/60Hz · · Operating temperature: -5 to +40 C · · Guarantee: 1 Year
-
CGD 40A Compact RCBO Type A WRCBO-B40/30/SPA
£18.96 Incl. VAT✓ In Stock for Delivery
Single module compact design RCBO, increasing the available wiring space within the consumer unit. Residual current circuit breaker with integral overcurrent protection. · · · Rated Current: 40A · · Trip Curve: B · · RCD Class: A · · Residual Current: 30mA · · Frequency: 50/60Hz · · Poles: 1P+N · · Din rail mounted · · For cable: 1 -16mm2
-
CGD MCB 32A Single Pole B Curve 6kA
£3.01 Incl. VAT✓ In Stock for Delivery
Designed to be used in our Steeple and Designa Curve consumer units, they are din rail mounted, designed to take a cable size from 1mm to 16mm and have a toggle with on/off indicator to switch the device on and off. This MCB provides protection against overloads, short circuits and infrequent switching of circuits under normal conditions. · · · Current Rating: 32A · · Rated short circuit capacity: 6kA · · Tripping Characteristic: B · · Terminal Tightening Torque: 2.5Nm · · Reference Standard: IEC / BS EN60898-4 · · Voltage 230V · · No. of modules: 1 x 18mm module · · Rated Frequency (Fn): 50/60Hz · · Operating temperature: -5 to +40 C · · Guarantee: 1 Year
-
CGD 20A Compact RCBO Type A WRCBO-B20/30/SPA
£18.96 Incl. VAT✓ In Stock for Delivery
Single module compact design RCBO, increasing the available wiring space within the consumer unit. Residual current circuit breaker with integral overcurrent protection. · · · Rated Current: 20A · · Trip Curve: B · · RCD Class: A · · Residual Current: 30mA · · Frequency: 50/60Hz · · Poles: 1P+N · · Din rail mounted · · For cable: 1 -16mm2
-
CGD 12 Way Consumer Unit with Main Switch and Surge Prefitted with Square Knockouts WQFS-MX12MS
£93.43 Incl. VAT✓ In Stock for Delivery
12 way metal clad consumer unit prefitted with 100A main switch and Type 2 surge protection that gives 9 useable ways. Incorporates rectangular knockouts for use with 25x40mm and 50x50mm mini trunking along with 32mm & 40mm diameter round knockouts for conduit, grommets and cable glands. This consumer unit is fully compliant with BSEN61439-3:2012 and Amendment 2 of the 18th Edition of the IET Wiring Regulations – BS7671 · · · 12 Modules with 9 useable ways · · 100A main switch fitted · · Type 2 surge protection fitted · · Square knockouts · · Dimensions: H:266 x W:281 x D106mm · · Rated operating voltage: 230V
-
CGD QFS-MX12M 10 Way Metal Clad Consumer Unit with 100A Isolator Incomer
£57.10 Incl. VAT✓ In Stock for Delivery
12 module metal clad consumer unit that comes with a 100A Main Isolator giving you 10 useable ways, designed to take our wide range of Steeple RCBO’s and MCB’s as well as Lewden RCBO’s and MCB’s. To make installation as easy as possible it has a wide selection of knockouts for conduit and mini trunking ranging from 25x40mm and 50x50mm trunking and 25mm and 32mm conduit knockouts. This consumer unit is fully compliant with the BSEN61439-3 (17th Edition Amendment 3 ) regulations. · · · 12 Module with 10 useable ways · · 100A Main Isolator · · IP2XC Rating · · Knockouts top, bottom, back and sides 20, 25 and 32mm · · Extra height for improved wiring space · · Supplied with circuit identification labels, phase insulators and module blanks · · Metal DIN Rail assembly / Top positioned Earth & Neutral terminals · · H:270mm x W:280mm x D:104mm · · Metal DIN Rail assembly / Top positioned Earth & Neutral terminals · · Steel – Powder coated to RAL9003
-
CGD Surge Retrofit Kit with Cable and MCB WSRG1VCU-KIT
£52.26 Incl. VAT✓ In Stock for Delivery
Surge Protection Device (SPD) is designed and is tested for use with CGD distribution boards. Easily add surge protection to existing boards with this retrofit surge protection kit, containing SPD, cables and 40A MCB. · · · Surge Protective Class: Type 2 · · Phase: 1 · · Modules: 2 · · Din rail mounted · · MCB: 40A · · Frequency: 50/60Hz
-
CGD 6A Compact RCBO Type A WRCBO-B06/30/SPA
£18.96 Incl. VAT✓ In Stock for Delivery
Single module compact design RCBO, increasing the available wiring space within the consumer unit. Residual current circuit breaker with integral overcurrent protection. · · · Rated Current: 6A · · Trip Curve: B · · RCD Class: A · · Residual Current: 30mA · · Frequency: 50/60Hz · · Poles: 1P+N · · Din rail mounted · · For cable: 1 -16mm2
-
CGD 32A Compact RCBO Type A WRCBO-B32/30/SPA
£18.96 Incl. VAT✓ In Stock for Delivery
Single module compact design RCBO, increasing the available wiring space within the consumer unit. Residual current circuit breaker with integral overcurrent protection. · · · Rated Current: 32A · · Trip Curve: B · · RCD Class: A · · Residual Current: 30mA · · Frequency: 50/60Hz · · Poles: 1P+N · · Din rail mounted · · For cable: 1 -16mm2
