1-Core 2.5mm ² Solid 6491X Cable 100m Blue

£53.82 Incl. VAT

6491X solid round PVC cable used in conduit wiring for distributor boards and switchboards. 6491X cable is a single core low voltage insulated cable manufactured in accordance with BS EN 50525-2-31 (previously BS6004) and is intended for use in closed installation ducts, and in embedded or semi-flush exposed conduits. · · · 2.5mm ² · · Blue · · 1 Core · · 450/750V rated · · Meets BS EN 50525-2-31:2011 standards · · Class 1 solid plain copper conductor to EN 60228 · · Length: 100m

54000 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 6491X-2.5-BLU100 CABLE-RX Categories: , , Brand: Part Number: 2500003069

Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Armouring/reinforcement None Conductor category Class 2 = stranded Core colour Blue Sheath colour Blue Conductor material Copper Core insulation material Polyvinyl chloride (PVC) Sheath material Polyvinyl chloride (PVC) Core identification Colour Conductor surface Bare Nominal cross sectional area of conductor 2.5 mm² Min. permitted bending radius, stationary application/permanent installation 22 mm Permitted cable outer temperature during assembling/handling 0 – 60 °C Nominal voltage U 750 V Nominal voltage U0 450 V Max. conductor temperature 70 °C Conductor Diameter 2.5 mm Number of cores 1 Outer diameter approx. 3.6 mm Low temperature resistant according to EN 60811-504+505+506 No Twisted cores No Oil resistant according to IEC 60811-404 No · Technical Data Sheet – Click to Download
