Wago 10 Way Compact Splicing Connector With Levers

Error-free electrical installations are guaranteed with splicing connector with levers (item number 221-420). From intercom system wiring to electric ovens—connecting various conductor types is quick and easy with WAGO’s practical 221 Series splicing connector. This splicing connector has a rated voltage of 450 V and can handle currents up to 32 A, making it ideal for high-load applications. Ensure that the strip lengths are 11 mm when connecting conductors to splicing connector with levers. This product features conductor terminals and utilizes CAGE CLAMP®. Our highly-rated and maintenance-free CAGE CLAMP® connection makes it easy to connect all conductor types without having to prepare the conductor. For example, you don’t need to crimp ferrules. The dimensions are 29.8 x 15.8 x 18.3 mm (width x height x depth). Splicing connector with levers is suitable for conductor cross sections ranging from 0.2 mm² to 4 mm². · · · Includes an operating lever · · 32A Rated · · Transparent housing for visual inspection shows that the wire is inserted properly and stripped to the correct length · · For all conductor types · · Up to 50% Reduced Wiring Time · · Easy Testing – Test Point on the front and rear of the housing · · Suitable applications e.g. Lighting, Power, HVAC and many more · · Suitable for use with Wagobox Enclosure
