Cable

Prysmian 6242BH 4.0mm² White Basec Cable 2-Core Twin & Earth

Brand: PrysmianProduct code: 20145102Go Magpie Ref: 5060062361781

Prysmian 6242B is a flat twin core Low Smoke, Zero Halogen (LSOH®) cable designed for installation as clipped direct, on tray or in basket and also buried within plaster or embedded in walls. Two cores with bare CPC · · · Suitable for fixed installation in dry or damp premises on walls, boards or trays, in channels or embedded in plaster. · · Suitable for situations in which low emission smoke and acid gas is required in case of burning. · · Length in metres: 100 · · No. of cores: 2 · · Product Packaging: Reel · · Suitable for domestic and commercial applications · · Low Smoke Zero Halogen · · 300/500V Operating voltage · · Standard: BS7211

£270.60inc VAT£225.50 ex VAT
In stock
UK deliveryStandard shipping is £2.99 inc VAT on eligible orders. Final delivery options are confirmed at checkout.
Quantity
1
✓ Secure checkout✓ UK customer support✓ Trusted suppliers
PRODUCT INFORMATION

Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Protective barrier None Core colour Several Conductor category Class 2 = stranded Conductor material Copper Conductor surface Bare Sheath colour White Sheath material Polyolefin Core insulation material Polyolefin Nominal voltage U0 300 V Core identification Colour Max. conductor temperature 90 °C Number of cores 2 Nominal cross sectional area of conductor 4 mm² Nominal voltage U 500 V Permitted cable outer temperature during assembling/handling 0 – 80 °C Drain wire Yes Oil resistant according to IEC 60811-404 No Low temperature resistant according to EN 60811-504+505+506 No Screen No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
