Commodity Cables 6491X 10.0mm² Black PVC Basec Cable Single 1-Core
£274.62 Incl. VAT
This product is packaged as 100m Reel. Hence when ordering, a mutiple of 100 needs to be entered. 6491X10.0 is a General Purpose Single Core Cable for use in conduit and trunking. 6491X Cable also known as H07-U and H07-R is a plain annealed copper stranded circular conductor. It is installed in surface mounted or embedded conduit or similar closed system and for fixed protected installation in or on lighting fitting and inside appliance, switchgear and control gear. Minimum bending radius is 3 x overall diameter. · · · Cable Size: 10.0mm² · · Colour: Black · · Length in metres: 100 · · No. of cores: 1 · · Product Packaging: Reel · · Material: PVC · · Standard: BS EN 50525-2-31
✓ In stock – Delivery in 1–2 days
Description
Technical Specifications Technical Specifications Power cable < 1 kV, for fixed installations Sheath colour Grey Conductor category Class 2 = stranded Conductor material Copper Core insulation material Polyvinyl chloride (PVC) Core colour Blue Conductor surface Bare Core identification Colour Nominal cross sectional area of conductor 10 mm² Nominal voltage U 750 V Conductor Diameter 10 mm Max. conductor temperature 70 °C Min. permitted bending radius, stationary application/permanent installation 38 mm Number of cores 1 Outer diameter approx. 6.3 mm Nominal voltage U0 450 V Permitted cable outer temperature during assembling/handling 0 – 60 °C Low temperature resistant according to EN 60811-504+505+506 No Oil resistant according to IEC 60811-404 No · Technical Data Sheet – Click to Download
