6491X 2.5mm Green/Yellow PVC Basec Cable 1-Core
6491X 2.5mm Green/Yellow PVC Basec Cable 1-Core
6491X 2.5mm Green/Yellow PVC Basec Cable 1-Core - Image 2
6491X 2.5mm Green/Yellow PVC Basec Cable 1-Core - Image 3

6491X 2.5mm Green/Yellow PVC Basec Cable 1-Core

£262.20 Incl. VAT

This product is packaged as 100m Reel. Hence when ordering, a mutiple of 100 needs to be entered. Solid conduit wire 450/750V voltage rated. · · · Cable Size: 2.5mm · · Colour: Green/Yellow · · Length in metres: 100 · · No. of cores: 1 · · Product Packaging: Reel · · Cut to Various Lengths: No · · Standard: BS EN 50525-2-31 · · Material: PVC · · Standard: BS EN 50525-2-31

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 6491X-2.5 Categories: , , Brand: Part Number: 1050373129

Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Sheath colour Blue Core colour Blue Conductor material Copper Armouring/reinforcement None Core insulation material Polyvinyl chloride (PVC) Sheath material Polyvinyl chloride (PVC) Max. conductor temperature 70 °C Nominal voltage U 750 V Nominal voltage U0 450 V Number of cores 1 Min. permitted bending radius, stationary application/permanent installation 22 mm Core identification Colour Conductor category Class 2 = stranded Conductor surface Bare Outer diameter approx. 3.6 mm Conductor Diameter 2.5 mm Nominal cross sectional area of conductor 2.5 mm² Permitted cable outer temperature during assembling/handling 0 – 60 °C Twisted cores No Low temperature resistant according to EN 60811-504+505+506 No Oil resistant according to IEC 60811-404 No · Technical Data Sheet – Click to Download
