Siemens 75kW/400V 1NO 24V DC 3P Screw Terminal
Siemens 75kW/400V 1NO 24V DC 3P Screw Terminal
Siemens 75kW/400V 1NO 24V DC 3P Screw Terminal - Image 2
Siemens 75kW/400V 1NO 24V DC 3P Screw Terminal - Image 3

Siemens 75kW/400V 1NO 24V DC 3P Screw Terminal

£98.80 Incl. VAT

Siemens contactors are suitable for every application as well as fully assembled contactor assemblies. The sirius devices are unique because of their high contact reliability, extremely long service life and the possibility of using them even in the most extreme ambient conditions. · · · Size of circuit breaker: S00 · · Size of contactor: S00 · · Climate-proof

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 3RT2018-1BB41 Categories: , , , , , Brand: Product Code: 1050391943

Description

Technical Specifications  Technical Specifications Power contactor, AC switching Type of electrical connection of main circuit Screw connection Voltage type for actuating DC Rated operation power at AC-3, 400 V 7.5 kW Number of auxiliary contacts as normally open contact 1 Number of main contacts as normally open contact 3 Rated operation power NEMA 7.35499 kW Rated operation current Ie at AC-4, 400 V 11.5 A Rated operation power at AC-4, 400 V 2.5 kW Rated operation current Ie at AC-1, 400 V 22 A Rated control supply voltage at AC 50 Hz 400 – 400 V Rated operation current Ie at AC-3, 400 V 16 A Modular version Yes Rated control supply voltage at DC 24 – 24 V · Technical Data Sheet – Click to Download
