Cembre 10mm² Copper lug M10 stud [Pack of 100]
Cembre 10mm² Copper lug M10 stud [Pack of 100]
Cembre 10mm² Copper lug M10 stud [Pack of 100] - Image 2
Cembre 10mm² Copper lug M10 stud [Pack of 100] - Image 3
Cembre 10mm² Copper lug M10 stud [Pack of 100] - Image 4

Cembre 10mm² Copper lug M10 stud [Pack of 100]

£0.74 Incl. VAT

10mm² Copper tube crimping lug M10 stud · · · Annealed to guarantee optimum ductility · · Insulation sleeve form to allow easy introduction of the conductor · · Maximum Voltage Rating: 11kV · · Operating Temperate Range -50°C to +150°C · · Manufactured from electrolytic Copper tube with a purity greater than 99.9% · · Electrolytically tin-plated to avoid oxidisation

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: A2-M10 Categories: , , Brand: Product Code: 2500003048

Description

Technical Specifications  Technical Specifications Copper tube crimping lug Material Copper AWG size 8 Connecting angle 180° (horizontal) Surface protection Tinned Number of fixing holes 1 Flange shape Ring shape Bolt dimension (metric) 10 Nominal cross section 10 mm² With sight-hole Yes Slender flange model No Insulated No · Technical Data Sheet – Click to Download
