A-M Tube Crimping Lug Copper 35mm² 8mm Stud - 400 Pack
A-M Tube Crimping Lug Copper 35mm² 8mm Stud - 400 Pack
A-M Tube Crimping Lug Copper 35mm² 8mm Stud - 400 Pack - Image 2
A-M Tube Crimping Lug Copper 35mm² 8mm Stud - 400 Pack - Image 3
A-M Tube Crimping Lug Copper 35mm² 8mm Stud - 400 Pack - Image 4

A-M Tube Crimping Lug Copper 35mm² 8mm Stud – 400 Pack

£1.02 Incl. VAT

35mm² Copper tube crimping lug M8 stud · · · Annealed to guarantee optimum ductility · · Insulation sleeve form to allow easy introduction of the conductor · · Maximum Voltage Rating: 11kV · · Operating Temperate Range -50°C to +150°C · · Manufactured from electrolytic Copper tube with a purity greater than 99.9% · · Electrolytically tin-plated to avoid oxidisation

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: A7-M8 Categories: , , Brand: Part Number: 2500003386

Description

Technical Specifications  Technical Specifications Copper tube crimping lug Connecting angle 180° (horizontal) Material Copper AWG size 2 Surface protection Tinned Conductor category Class 5 = flexible Bolt dimension (metric) 8 Flange shape Ring shape Number of fixing holes 1 Nominal cross section 35 mm² Insulated No With sight-hole Yes Slender flange model No · Technical Data Sheet – Click to Download
