Cembre 50mm² Copper lug M8 stud [Pack of 50]
Cembre 50mm² Copper lug M8 stud [Pack of 50]
Cembre 50mm² Copper lug M8 stud [Pack of 50] - Image 2
Cembre 50mm² Copper lug M8 stud [Pack of 50] - Image 3
Cembre 50mm² Copper lug M8 stud [Pack of 50] - Image 4

Cembre 50mm² Copper lug M8 stud [Pack of 50]

£1.99 Incl. VAT

50mm² Copper tube crimping lug M8 stud · · · Annealed to guarantee optimum ductility · · Insulation sleeve form to allow easy introduction of the conductor · · Maximum Voltage Rating: 11kV · · Operating Temperate Range -50°C to +150°C · · Manufactured from electrolytic Copper tube with a purity greater than 99.9% · · Electrolytically tin-plated to avoid oxidisation

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: A10-M8 Categories: , , Brand: Product Code: 2500005311

Description

Technical Specifications  Technical Specifications Copper tube crimping lug Material Copper Connecting angle 180° (horizontal) AWG size 1 Flange shape Ring shape Surface protection Tinned Bolt dimension (metric) 8 Nominal cross section 50 mm² Insulated No Number of fixing holes 1 Slender flange model No With sight-hole Yes · Technical Data Sheet – Click to Download
