Cembre 70mm² Copper lug M10 stud [Pack of 50]
Cembre 70mm² Copper lug M10 stud [Pack of 50]
Cembre 70mm² Copper lug M10 stud [Pack of 50] - Image 2
Cembre 70mm² Copper lug M10 stud [Pack of 50] - Image 3
Cembre 70mm² Copper lug M10 stud [Pack of 50] - Image 4

Cembre 70mm² Copper lug M10 stud [Pack of 50]

£2.89 Incl. VAT

70mm² Copper tube crimping lug M10 stud · · · Annealed to guarantee optimum ductility · · Insulation sleeve form to allow easy introduction of the conductor · · Maximum Voltage Rating: 11kV · · Operating Temperate Range -50°C to +150°C · · Manufactured from electrolytic Copper tube with a purity greater than 99.9% · · Electrolytically tin-plated to avoid oxidisation

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: A14-M10 Categories: , , Brand: Product Code: 2500005368

Description

Technical Specifications  Technical Specifications Copper tube crimping lug Material Copper AWG size 00 Connecting angle 180° (horizontal) Surface protection Tinned Flange shape Ring shape Number of fixing holes 1 Bolt dimension (metric) 10 With sight-hole Yes Nominal cross section 70 mm² Insulated No Slender flange model No · Technical Data Sheet – Click to Download
