ABB CA4-22M Auxiliary Contact Block
£26.78 Incl. VAT
ABB 1SBN010140R1122 CA4-22M 2NO/2NC auxiliary contact block is suitable for AF09/AF12/AF16 contractors. It features screw terminal type, 10mm wire stripping length, 11 in-lbs tightening torque and 6kV rated impulse withstand voltage (Uimp). 16A conventional free-air thermal current (Ith) according to IEC 60947-5-1. · · · Mounting Type: Front · · Range: AF · · Weight: 14g · · Normal State Configuration: 2NO/2NC
Out of Stock
Description
Technical Specifications Technical Specifications Auxiliary contact block Rated operation current Ie at AC-15, 230 V 4 A Number of contacts as normally closed contact 2 Number of fault-signal switches 0.00 Number of contacts as change-over contact 0.00 Number of contacts as normally open contact 2 · Technical Data Sheet – Click to Download
