ABB CA5-01 Auxiliary Contact Block
ABB CA5-01 Auxiliary Contact Block
ABB CA5-01 Auxiliary Contact Block - Image 2

ABB CA5-01 Auxiliary Contact Block

£9.14 Incl. VAT

ABB CA5-01 1 Pole 1NC auxiliary contact block is suitable for A9 to A110 A-Line contactors. It features screw terminal type, 0.1W per pole power loss, IP20 degree of protection according to IEC 60529, IEC 60947-1, EN 60529. 50/60Hz supply circuit rated frequency . 10 x Ie AC-15 rated making capacity according to IEC 60947-5-1. · · · Height: 47mm · · Mounting Type: Front Face · · Range: A-Line · · Width: 11mm · · Weight: 14g · · Depth: 32.5mm · · Normal State Configuration: 1NC

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 1SBN010010R1001 Categories: , , Product Code: 2500073225

Description

Technical Specifications  Technical Specifications Auxiliary contact block Number of contacts as normally closed contact 1 Rated operation current Ie at AC-15, 230 V 4 A Number of fault-signal switches 0.00 Number of contacts as change-over contact 0.00 Number of contacts as normally open contact 0.00 · Technical Data Sheet – Click to Download
