ABB CR-M012DC2L Pluggable interface relay 2c/o – A1-A2=12VDC – 250V/12A – LED
£8.45 Incl. VAT
The CR-M012DC2L Pluggable Interface Relay Is From The CR-M (Miniature) Relay Range. This Relay Operates With A 12 V DC Rated Control Supply Voltage And Has A 2 C/O (SPDT) Output With Contacts Rated At 250 V / 12 A. The Relay Has An Integrated Blue Test Button For Manual Actuation And Locking Of The Output Contacts And An Integrated LED. Standard Sockets, Logic Sockets, Pluggable Function Modules, Holder And Marker Are Available As Accessories. · · · 4 different coil voltages · · DC versions: 12 V, 24 V · · AC versions: 24 V, 230 V · · Output contacts · · 4 c/o contacts (6 A) optionally equipped with gold contacts · · Integrated test button for manual actuation and locking of the output contacts (blue = DC, orange = AC) that can be removed if necessary · · Logical or standard sockets · · Cadmium-free contact material · · Width on socket: up to 31 mm · · Pluggable functional modules
Description
Technical Specifications Technical Specifications Switching relay Nominal current 12 A Depth 27.5 mm Height 35.6 mm Number of contacts as normally closed contact 0.00 Number of contacts as normally open contact 0.00 Width 21.2 mm Number of contacts as change-over contact 2 Rated control supply voltage at AC 50 Hz – – – V Rated control supply voltage at DC 12 – 12 V Rated control supply voltage at AC 60 Hz – – – V With LED indication Yes With detachable clamps No With forced-guided contacts No Complete with socket No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
