ABB MS132-0.63 Manual Motor Starter
£98.59 Incl. VAT
The MS132-0.63 Manual Motor Starter (Also Known As Motor Protection Circuit Breaker Or Manual Motor Protector) Is A Compact 45 Mm Width Device With A Rated Operational Current Of Ie = 0.63 A. This Device Is Used To Manually Switch On And Off Motors And To Protect Them Reliably And Without The Need For A Fuse From Short-Circuits, Overload And Phase Failures. The Manual Motor Starter Offers A Rated Service Short-Circuit Breaking Capacity Ics = 100 KA At 400 VAC And Trip Class 10. Further Features Are The Build-In Disconnect Function, Temperature Compensation, Trip-Free Mechanism And A Rotary Handle With A Clear Switch Position Indication. The Manual Motor Starter Is Suitable For Three- And Single-Phase Applications. The Handle Is Lockable To Protect Against Unauthorized Changes. Auxiliary Contacts, Signaling Contacts, Undervoltage Releases, Shunt Trips, 3-Phase Bus Bars, Power In-Feed Blocks And Terminal Spacers Are Available As Accessory. · · · Manual Motor Starter · · Thermal and Short Circuit Protection · · Trip Free Mechanism
Out of Stock
Description
Technical Specifications Technical Specifications Motor protection circuit-breaker Width 45 mm Rated operation power at AC-3, 400 V 0.18 kW Number of poles 3 Rated operation power at AC-3, 230 V 0.18 kW Rated permanent current Iu 0.63 A Depth 86.75 mm Height 90 mm Rated short-circuit breaking capacity Icu at 400 V, AC 100 kA Rated operating voltage 250 – 690 V Overload release current setting 0.4 – 0.63 A Adjustment range undelayed short-circuit release 7.9 – 7.9 A With integrated auxiliary switch No With integrated under voltage release No With thermal overload protection Yes Phase failure sensitive Yes · Technical Data Sheet – Click to Download
