ABB S201M-C2 Miniature Circuit Breaker - 1P - C - 2 A
Awaiting product image

ABB S201M-C2 Miniature Circuit Breaker – 1P – C – 2 A

£22.91 Incl. VAT

ABB 2CDS271001R0024 1 Pole 2A Type C MCB with Failsafe bi-directional cylinder-lift screw terminal. This System pro M compact S201M-C2 MCB is current limiting device. It is comply with IEC/EN 60898-1 and IEC/EN 609 47-2. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space. It provides moderate switching surges for short durations. It has metal framed trip-free switching mechanism. · · · Breaking Capacity: 10kA · · Colour: Light Grey · · Current Rating: 2A · · Height: 88mm · · Range: System pro M Compact · · Width: 17.5mm · · Weight: 125g · · Depth: 69mm

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 2CDS271001R0024 Categories: , , , Product Code: 2500179707

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Rated current 2 A Recess depth 69 mm Width in number of modular spacings 1 Rated voltage 230 V Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Rated insulation voltage Ui 440 V Number of poles (total) 1 Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Current limiting class 3 Pollution degree 3 Number of protected poles 1 Over voltage category 3 Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 15 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 15 kA Frequency 50 – 60 Hz Ambient temperature during operating -25 – 55 °C Connectable conductor cross section multi-wired 0.75 – 25 mm² Connectable conductor cross section solid-core 0.75 – 35 mm² Concurrently switching N-neutral No Flush-mounted installation No Explosion-proof No Additional equipment possible Yes
