ABB S202M-C10 Miniature Circuit Breaker - 2P - C - 10 A
Awaiting product image

ABB S202M-C10 Miniature Circuit Breaker – 2P – C – 10 A

£57.14 Incl. VAT

System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space. · · · 10 ampere · · (230 V AC) 7.5 kiloampere · · 2 Pole

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 2CDS272001R0104 Categories: , , , Product Code: 2500179878

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Rated current 10 A Rated insulation voltage Ui 440 V Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Number of protected poles 2 Number of poles (total) 2 Recess depth 69 mm Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated voltage 400 V Current limiting class 3 Pollution degree 3 Over voltage category 3 Width in number of modular spacings 2 Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 25 kA Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 15 kA Frequency 50 – 60 Hz Ambient temperature during operating -25 – 55 °C Connectable conductor cross section multi-wired 0.75 – 25 mm² Connectable conductor cross section solid-core 0.75 – 35 mm² Flush-mounted installation No Additional equipment possible Yes Concurrently switching N-neutral No Explosion-proof No
