ABB S203-K32 Miniature Circuit Breaker – 3P – K – 32 A
£110.34 Incl. VAT
System Pro M Compact S200 Miniature Circuit Breakers Are Current Limiting. They Have Two Different Tripping Mechanisms, The Delayed Thermal Tripping Mechanism For Overload Protection And The Electromechanic Tripping Mechanism For Short Circuit Protection. They Are Available In Different Characteristics (B,C,D,K,Z), Configurations (1P,1P+N,2P,3P,3P+N,4P), Breaking Capacities (Up To 6 KA At 230/400 V AC) And Rated Currents (Up To 63A). All MCBs Of The Product Range S200 Comply With IEC/EN 60898-1, IEC/EN 60947-2, UL1077 Allowing The Use For Residential, Commercial And Industrial Applications. Bottom-Fitting Auxiliary Contact Can Be Mounted On S200 To Save 50% Space. · · · Miniature Circuit Breaker · · (230 V AC) 6 kiloampere · · 3 Pole
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Rated current 32 A Recess depth 69 mm Rated voltage 400 V Width in number of modular spacings 3 Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 20 kA Rated insulation voltage Ui 440 V Number of protected poles 3 Current limiting class 3 Number of poles (total) 3 Over voltage category 3 Pollution degree 3 Rated short-circuit breaking capacity Icn EN 60898 at 230 V – kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 10 kA Frequency 50 – 60 Hz Connectable conductor cross section multi-wired 0.75 – 25 mm² Connectable conductor cross section solid-core 0.75 – 35 mm² Ambient temperature during operating -25 – 55 °C Additional equipment possible Yes Concurrently switching N-neutral No Explosion-proof No Flush-mounted installation No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
