ABB SH202-C6 Miniature Circuit Breaker – 2P – C – 6 A

£66.62 Incl. VAT

Compact Home SH200 Miniature Circuit Breakers Are Current Limiting. They Have Two Different Tripping Mechanisms, The Delayed Thermal Tripping Mechanism For Overload Protection And The Electromechanic Tripping Mechanism For Short Circuit Protection. They Are Available In Different Characteristics (B,C), . Configurations (1P,1P+N,2P,3P,3P+N,4P), Breaking Capacities (Up To 6 KA At 230/400 V AC) And Rated Currents (Up To 40 A). All MCBs Of The Product Range SH200 Comply With IEC/EN 60898-1, Allowing The Use For Residential Applications. · · · Miniature Circuit Breaker · · 50 … 60Hz · · IP20

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 2CDS212001R0064 Categories: , , Brand: Product Code: 2501049684

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Rated current 6 A Current limiting class 3 Rated impulse-withstand voltage (Uimp) 4 kV Over voltage category 3 Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V – kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated voltage 400 V Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V – kA Rated insulation voltage Ui 440 V Recess depth 69 mm Rated short-circuit breaking capacity Icn EN 60898 at 230 V – kA Number of protected poles 2 Pollution degree 2 Number of poles (total) 2 Width in number of modular spacings 2 Frequency 50 – 60 Hz Connectable conductor cross section multi-wired 0.75 – 16 mm² Connectable conductor cross section solid-core 0.75 – 25 mm² Ambient temperature during operating -25 – 55 °C Explosion-proof No Flush-mounted installation No Additional equipment possible No Concurrently switching N-neutral No
