ABB SN201 M-C2 Miniature circuit breaker - 1+NP - C - 2 A
ABB SN201 M-C2 Miniature circuit breaker - 1+NP - C - 2 A
ABB SN201 M-C2 Miniature circuit breaker - 1+NP - C - 2 A - Image 2

ABB SN201 M-C2 Miniature circuit breaker – 1+NP – C – 2 A

£37.69 Incl. VAT

The SN201 Series Miniature Circuit Breaker Is A 1P+N Single-Module Device For The Protection Of Circuits Against Overload And Short Circuit. It Is Suitable For The Application In Final Distribution And Protection Of Long Cable Lenghts In TN And IT Systems · · · Miniature circuit breaker · · (230 V AC) 7.5 kiloampere · · 1+N Pole

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 2CSS275101R0024 Categories: , , Brand: Product Code: 2500375163

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Rated voltage 230 V Width in number of modular spacings 1 Recess depth 69 mm Rated current 2 A Number of poles (total) 2 Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Pollution degree 2 Rated short-circuit breaking capacity Icn EN 60898 at 400 V – kA Rated insulation voltage Ui 500 V Number of protected poles 1 Rated impulse-withstand voltage (Uimp) 4 kV Over voltage category 3 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V – kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 10 kA Current limiting class 3 Frequency 50 – 60 Hz Connectable conductor cross section multi-wired 1 – 10 mm² Connectable conductor cross section solid-core 1 – 16 mm² Ambient temperature during operating -25 – 55 °C Explosion-proof No Additional equipment possible Yes Concurrently switching N-neutral Yes Flush-mounted installation No · Technical Data Sheet – Click to Download · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1600400 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1600401
