ABB XT1C 160 TMD 100-1000 3p F F
£305.53 Incl. VAT
ABB XT1C Moulded Case Circuit Breaker with XT1C160 front terminals and thermomagnetic release. It is associated with power distribution. It has a fixed dimension of copper depending on the quantity. · · · Front terminals and thermomagnetic release · · Associated with power distribution · · Has a fixed dimension of copper depending on the quantity · · Icu (415 V) = 25 kA · · ln = 100A
Out of Stock
Description
Technical Specifications Technical Specifications Moulded case circuit breaker (MCCB) Number of auxiliary contacts as change-over contact 0.00 Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 25 kA Number of poles 3 Number of auxiliary contacts as normally closed contact 0.00 Rated permanent current Iu 100 A Overload release current setting 70 – 100 A Number of auxiliary contacts as normally open contact 0.00 Rated voltage 690 – 690 V Adjustment range short-term delayed short-circuit release – – – A Adjustment range undelayed short-circuit release 1000 – 1000 A With integrated under voltage release No Integrated earth fault protection No Suitable for DIN rail (top hat rail) mounting No Motor drive integrated No Motor drive optional Yes DIN rail (top hat rail) mounting optional No Switched-off indicator available No Complete device with protection unit Yes · Technical Data Sheet – Click to Download · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1667322 · DOP: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/1667324
