ABB XT1N 160 TMD 63-630 3p F F
ABB XT1N 160 TMD 63-630 3p F F
ABB XT1N 160 TMD 63-630 3p F F - Image 2

ABB XT1N 160 TMD 63-630 3p F F

£313.25 Incl. VAT

C.BREAKER TMAX XT1N 160 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMD R 63-630 A · · · Moulded Case Circuit Breaker · · Rated Current 63A · · 3 Pole

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 1SDA067414R1 Categories: , , Brand: Product Code: 2501035375

Description

Technical Specifications  Technical Specifications Moulded case circuit breaker (MCCB) Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 36 kA Number of auxiliary contacts as change-over contact 0.00 Number of auxiliary contacts as normally open contact 0.00 Number of auxiliary contacts as normally closed contact 0.00 Rated permanent current Iu 63 A Number of poles 3 Overload release current setting 44.1 – 63 A Adjustment range short-term delayed short-circuit release – – – A Adjustment range undelayed short-circuit release 630 – 630 A Rated voltage 690 – 690 V Motor drive integrated No Motor drive optional Yes Switched-off indicator available No DIN rail (top hat rail) mounting optional No Complete device with protection unit Yes With integrated under voltage release No Integrated earth fault protection No Suitable for DIN rail (top hat rail) mounting No
