Aico Ei428 RadioLINK Relay Module Mains Powered with Rechargeable Battery

The Ei428 switches a relay to activate external devices when an alarm in the system is triggered. The electrically isolated contacts can be used for many applications such as signalling, turning on lights, strobes etc. It has volt-free contacts (Normally Open and Normally Closed) as standard but can be wired to give a 230V output or 24V output using an external 24V supply. The Ei428 is mains powered and has a backup rechargeable lithium cells in the event of mains power failure. Lithium cells have a 10 year lifespan and are designed to last for the working life of the relay. They will provide up to 2 months operation in the event of a mains power failure. It is primarily designed to work with other enabled alarms and devices. For additional flexibility the Ei428 can also be used with conventional hard wired interconnect system. As supplied the relay operates continuously but can be easily adjusted to pulse condition. Compatible with the Ei2110e multi sensor fire alarm, 160e series alarms, the 140RC series and RadioLINK+ carbon monoxide alarms. Connects with the alarm system through RadioLINK wireless technology. · · · Triggers external devices if alarm is activate · · Mains powered with battery backup · · RadioLINK wireless interconnection · · Up to 12 alarms and devices can be interconnected · · Additional trunking knockouts · · Continuous or pulse operation · · Volt-free relay contacts · · Clear LED indicator · · Aico Ei428
