Auxiliary Contact Block TeSys Instantaneous 600V AC 10A 3NO/1NC
Auxiliary Contact Block TeSys Instantaneous 600V AC 10A 3NO/1NC
Auxiliary Contact Block TeSys Instantaneous 600V AC 10A 3NO/1NC - Image 2
Auxiliary Contact Block TeSys Instantaneous 600V AC 10A 3NO/1NC - Image 3
Auxiliary Contact Block TeSys Instantaneous 600V AC 10A 3NO/1NC - Image 4

Auxiliary Contact Block TeSys Instantaneous 600V AC 10A 3NO/1NC

£18.29 Incl. VAT

Schneider Electric LA1KN31 3NO/1NC TeSys K instantaneous auxiliary contact block is suitable for CA2K/CA3K relays, with screw-clamps terminals. It features <= 690V AC <=400Hz [Ue] rated operational voltage, 10A at <=50°C [Ith] conventional free air thermal current, 110A at 10MOhm for control circuit insulation resistance. · · · TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). · · It provides 3NO+1NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. · · Range: TeSys K · · Front mounting by clip-on, it procures high reliability and durability. · · Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh). · · Depth: 35mm · · Normal State Configuration: 3NO/1NC · · CE: yes

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: LA1KN31 Categories: , , Brand: Part Number: 2500058156

Description

Technical Specifications  Technical Specifications Auxiliary contact block Number of contacts as normally closed contact 1.00 Rated operation current Ie at AC-15, 230 V 10.00 A Number of fault-signal switches 0.00 Number of contacts as normally open contact 3.00 Number of contacts as change-over contact 0.00 · Technical Data Sheet – Click to Download
