Bticino Cable Connection Pbsf 620mm

Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for flexible applications Sheath colour Grey Conductor category Class 5 = flexible Sheath material Polyvinyl chloride (PVC) Core insulation material Polyvinyl chloride (PVC) Weight – kg/km Min. permitted bending radius, stationary application/permanent installation – mm Number of cores 6 Nominal voltage U0 300 V Max. conductor temperature – °C Min. permitted bending radius, moving application/free movement – mm Min. permitted bending radius, moving application with forced guidance – mm Number of strands per conductor – Outer diameter approx. – mm Conductor resistance at 20 °C – Ohm/km Strand diameter – mm Max. tensile strength during installation – kN Nominal cross sectional area of pilot/reduced conductors (AWG) – Nominal cross sectional area of conductor (AWG) – kcmil Cable width approx. 7.6 mm Number of pilot/reduced cores – Nominal cross sectional area of pilot/reduced conductors – mm² Number of stranding elements – Nominal voltage U 50 V Cable height approx. 620 mm Nominal cross sectional area of conductor 0.32 mm² Permitted cable outer temperature after assembling without vibration – – – °C Permitted cable outer temperature during assembling/handling -55 – 105 °C Halogen free according to IEC 60754-3 No Low temperature resistant according to EN 60811-504+505+506 No Oil resistant according to IEC 60811-404 No Screen No Torsion resistant No Low smoke according to IEC 61034-2 No Drain wire No Halogen free according to IEC 60754-2 No Flame retardant according to IEC 60332-3-23 (Cat B) No Flame retardant according to IEC 60332-3-22 (Cat A) No Flame retardant according to IEC 60332-3-21 (Cat A F/R) No Flame retardant according to IEC 60332-1-2 No Flame retardant according to IEC 60332-3-25 (Cat D) No Flame retardant according to IEC 60332-3-24 (Cat C) No Halogen free according to IEC 60754-1 No With protective conductor No Core identification according to HD 308 S2 No · Technical Data Sheet – Click to Download
