Description

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Sheath colour Brown Conductor category Class 2 = stranded Armouring/reinforcement None Nominal cross sectional area of conductor 1.5 mm² Nominal voltage U 750 V Conductor Diameter 1.5 mm Conductor surface Bare Conductor material Copper Core identification Colour Core colour Blue Max. conductor temperature 90 °C Outer diameter approx. 3 mm Number of cores 1 Nominal voltage U0 450 V Permitted cable outer temperature during assembling/handling 0 - 80 °C Oil resistant according to IEC 60811-404 No Twisted cores No Low temperature resistant according to EN 60811-504+505+506 No · Technical Data Sheet – Click to Download
