Commodity Cables Cable Single Core Conduit Wire PVC Priced Per Mtr 4mm Grey

Technical Specifications  Technical Specifications Power cable < 1 kV, for fixed installations Conductor category Class 2 = stranded Armouring/reinforcement None Core colour Blue Sheath colour Blue Conductor material Copper Sheath material Polyvinyl chloride (PVC) Min. permitted bending radius, stationary application/permanent installation 26 mm Conductor Diameter 4 mm Number of cores 1 Outer diameter approx. 4.2 mm Nominal cross sectional area of conductor 4 mm² Conductor surface Bare Core identification Colour Core insulation material Polyvinyl chloride (PVC) Max. conductor temperature 70 °C Nominal voltage U0 450 V Nominal voltage U 750 V Permitted cable outer temperature during assembling/handling 0 – 60 °C Twisted cores No Low temperature resistant according to EN 60811-504+505+506 No Oil resistant according to IEC 60811-404 No · Technical Data Sheet – Click to Download
