CEENorm Socket Panel 3P+E IP67

Description

Technical Specifications  Technical Specifications Panel-mounted CEE socket outlet Material Plastic Degree of protection (IP rating) IP67 Identification colour Blue Angle of plug Straight Connection system Screwed terminal Voltage acc. EN 60309-2 230 V (50+60 Hz) blue Contact material CuZn Surface finish contacts Untreated Number of poles 4 RAL number 5015 Drill hole distance vertical 52 mm Amperage acc. UL/CSA (for UL-version) – A Drill hole distance horizontal 52 mm Flange size vertical 72 mm Flange size horizontal 65 mm IEC-amperage 16 A Clock hour position 9 h Rated frequency – Hz Rated voltage – V Military model No
