CEENorm Socket Switched Double-Interlocked 2P+E IP44
Awaiting product image

CEENorm Socket Switched Double-Interlocked 2P+E IP44

£158.48 Incl. VAT

CEENorm UK 16167 Socket Switched Double-Interlocked 2P+E 16A 240V Blue IP44 · · · Product: Socket · · Type: switch interlocked · · Pole Configuration: Double Pole + Earth (2P+E) · · Number of Pins: 3 · · Pin Shape: Round · · Clock Reference: 6 · · Ingress Protection: IP44 · · Accessories Included: Screw Terminal · · Colour: Blue · · Length: 188.5 mm

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 16167 Categories: , , , Brand: Product Code: 2500037085

Description

Technical Specifications  Technical Specifications CEE switched socket outlet Model Base unit and cover Protection None Housing material Plastic Degree of protection (IP rating) IP44 Surface finish contacts Nickel-plated Switch Mechanical locking Type of switch Special switch Identification colour Blue Voltage acc. EN 60309-2 230 V (50+60 Hz) blue Number of poles 3 IEC-amperage 16 A Amperage acc. UL/CSA (for UL-version) – A Military model No Clock hour position 6 h Empty locations on mounting rail No With earth leakage switch No · Technical Data Sheet – Click to Download
