Cembre ANE2-M8 Lug 10Mm2
Cembre ANE2-M8 Lug 10Mm2
Cembre ANE2-M8 Lug 10Mm2 - Image 2
Cembre ANE2-M8 Lug 10Mm2 - Image 3

Cembre ANE2-M8 Lug 10Mm2

£0.80 Incl. VAT

10mm² Polyamide PA6.6 insulated copper tube crimping lug M8 stud black · · · Insulation sleeve in Polyamide PA6.6 · · Facilitated introduction of the conductor · · -25°C to +115°C Temperature Range · · Electrolytically tin-plated to avoid oxidisation · · Manufactured from electrolytic Copper wire with a purity greater than 99.9% · · inspection hole for checkin conductor

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: ANE2-M8 Categories: , Brand: Product Code: 2500111768

Description

Technical Specifications  Technical Specifications Copper tube crimping lug Material Copper AWG size 8 Colour insulation Black Connecting angle 180° (horizontal) Surface protection Tinned Flange shape Ring shape Bolt dimension (metric) 8 Number of fixing holes 1 Slender flange model No Nominal cross section 10 mm² With sight-hole Yes Insulated Yes
