Cembre Copper Through Connector
£1.60 Incl. VAT
50mm² Copper tube through connector · · · Annealed to guarantee optimum ductility · · Facilitated introduction of the conductor · · -50°C to +150°C Temperature Range · · Maximum Voltage Rating: 11kV · · Manufactured from electrolytic Copper tube with a purity greater than 99.9% · · Electrolytically tin-plated to avoid oxidisation · · Length Min Max: 37 mm · · Standards: IEC61238-1
Out of Stock
Description
Technical Specifications Technical Specifications Crimp splices for copper conductor Voltage row Up to 600 V Insulation None Material Copper Sleeve form Long Surface protection Tinned Model Standard version Type of connection Percussion connector Nominal current – A Number of branches – Useful for stranded conductors Yes Nominal cross section 50 – 50 mm² Suitable for round conductors Yes Suitable for solid cores No Suitable for fine strand conductors Yes Suitable for insulated varnish No Suitable for high temperatures (to 650 °C) No Suitable for flat conductors No For pull protected connections No Oil stop/centre bar Yes · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/573526
