Circuit Breaker basic frame, ComPacT NSX100N, 50 kA at 415 VAC 50/60 Hz, 100 A, without Trip Unit, 3 poles
Circuit Breaker basic frame, ComPacT NSX100N, 50 kA at 415 VAC 50/60 Hz, 100 A, without Trip Unit, 3 poles
Circuit Breaker basic frame, ComPacT NSX100N, 50 kA at 415 VAC 50/60 Hz, 100 A, without Trip Unit, 3 poles - Image 2
Circuit Breaker basic frame, ComPacT NSX100N, 50 kA at 415 VAC 50/60 Hz, 100 A, without Trip Unit, 3 poles - Image 3
Circuit Breaker basic frame, ComPacT NSX100N, 50 kA at 415 VAC 50/60 Hz, 100 A, without Trip Unit, 3 poles - Image 4

Circuit Breaker basic frame, ComPacT NSX100N, 50 kA at 415 VAC 50/60 Hz, 100 A, without Trip Unit, 3 poles

£260.82 Incl. VAT

· · This is a 3 poles basic frame for ComPacT NSX100N. · · ComPacT NSX is designed to optimize space and breaking capacity for all standard and specific applications. · · This basic frame comes without trip unit, and is compatible with any type of trip unit ordered separately. · · The breaking capacity Icu is 50kA at 415VAC 50/60Hz. · · The operational voltage is 690VAC 50/60Hz (limited to 440VAC 50/60Hz if there is an earth-leakage protection). · · It can be equipped with a variety of optional functions and accessories. · · The dimensions are 105mm x 161mm x 86mm. · · It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. · · ComPacT NSX100N is part of Schneider Electric EcoStruxure Power architecture.

6 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: C10N3 Categories: , , Brand: Part Number: 2501491535

Description

Technical Specifications  Technical Specifications Moulded case circuit breaker (MCCB) Degree of protection (IP rating) IP40 Position of connection for main current circuit Front Device construction Built-in device fixed built-in technique Type of electrical connection of main circuit Screw connection Type of control element Toggle Number of auxiliary contacts as normally closed contact 0 Number of auxiliary contacts as normally open contact 0 Rated permanent current Iu 100 A Number of poles 3 Number of auxiliary contacts as change-over contact 0 Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 50 kA Overload release current setting – – – A Adjustment range undelayed short-circuit release – – – A Adjustment range short-term delayed short-circuit release – – – A Rated voltage 690 – 690 V Power loss 14.1 W Motor drive optional Yes Motor drive integrated No DIN rail (top hat rail) mounting optional Yes Switched-off indicator available Yes Complete device with protection unit No With integrated under voltage release No Integrated earth fault protection No Suitable for DIN rail (top hat rail) mounting No
