Circuit Breaker basic frame, ComPacT NSX250F, 36 kA at 415 VAC 50/60 Hz, 250 A, without Trip Unit, 4 poles
Circuit Breaker basic frame, ComPacT NSX250F, 36 kA at 415 VAC 50/60 Hz, 250 A, without Trip Unit, 4 poles
Circuit Breaker basic frame, ComPacT NSX250F, 36 kA at 415 VAC 50/60 Hz, 250 A, without Trip Unit, 4 poles - Image 2
Circuit Breaker basic frame, ComPacT NSX250F, 36 kA at 415 VAC 50/60 Hz, 250 A, without Trip Unit, 4 poles - Image 3
Circuit Breaker basic frame, ComPacT NSX250F, 36 kA at 415 VAC 50/60 Hz, 250 A, without Trip Unit, 4 poles - Image 4

Circuit Breaker basic frame, ComPacT NSX250F, 36 kA at 415 VAC 50/60 Hz, 250 A, without Trip Unit, 4 poles

£645.84 Incl. VAT

· · This is a 4 poles basic frame for ComPacT NSX250F. · · ComPacT NSX is designed to optimize space and breaking capacity for all standard and specific applications. · · This basic frame comes without trip unit, and is compatible with any type of trip unit which has to be ordered separately · · The breaking capacity Icu is 36kA at 415VAC 50/60Hz. · · The operational voltage is 690VAC 50/60Hz (limited to 440VAC 50/60Hz if there is an earth-leakage protection). · · It can be equipped with a variety of optional functions and accessories. · · The dimensions are 140mm x 161mm x 86mm. · · It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. · · ComPacT NSX250F is part of Schneider Electric EcoStruxure Power architecture.

5 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: C25F4 Categories: , , Brand: Part Number: 2501503908

Description

Technical Specifications  Technical Specifications Moulded case circuit breaker (MCCB) Degree of protection (IP rating) IP40 Position of connection for main current circuit Front Device construction Built-in device fixed built-in technique Type of electrical connection of main circuit Screw connection Type of control element Toggle Number of auxiliary contacts as normally open contact 0 Rated permanent current Iu 250 A Power loss 70.4 W Number of auxiliary contacts as change-over contact 0 Number of auxiliary contacts as normally closed contact 0 Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 36 kA Overload release current setting – – – A With integrated under voltage release No Motor drive integrated No Motor drive optional Yes Adjustment range undelayed short-circuit release – – – A Adjustment range short-term delayed short-circuit release – – – A Rated voltage 690 – 690 V Number of poles 4 Integrated earth fault protection No Suitable for DIN rail (top hat rail) mounting No DIN rail (top hat rail) mounting optional Yes Switched-off indicator available Yes Complete device with protection unit No
