CMP Washer Entry Thread Sealing 25mm White Nylon

The CMP metric entry thread sealing washers are produced in 2mm thick white nylon* as standard which are recommended and meet the specified requirements of Shell’s offshore operations · · · To maintain the Ingress Protection rating between the equipment and the Cable Gland · · It may be necessary to fit an Entry Thread Sealing Washer at the equipment-to-gland entry interface · · For installations it is equally essential to maintain the ingress protection integrity at which the equipment has been rated · · The need for a sealing washer will depend on the ingress protection rating code of protection of the equipment and the type of entry holes available within that equipment · · For example: – when using Ex e equipment or terminal enclosures (which are permitted to have untapped through-clearance holes) it will be necessary to fit a sealing washer to ensure the minimum IP54 requirement is met · · Other equipment with tapped entry holes may not require a sealing washer to maintain the IP54 minimum rating. · · The CMP metric Entry Thread Sealing Washers are produced in 2mm thick white nylon as standard · · To verify the effectiveness of the CMP nylon entry sealing washers · · Independent 3rd party tests to IEC 60529 have been successfully conducted on Cable Gland at IP66
