Competitive Price Wholesale Intel LGA1170 DDR3 8GB RAM SATA Single Channel Motherboard VGA HD-MI LVDS 3 Display Ports Desktop

Description

Product description

Specification Model No. EP-4120 CPU Onboard Intel J1900 Processor Chipset Intel BayTrail | Maximum power consumption:10W Memory 1 SO_DIMM sockets, Support Dual Channel DDR3L/ 1333 MHz SDRAM up to 8GB | Not support ECC BIOS AMI EFI BIOS Super I/O Winbond W83627DHG-P | COM1 COM2 extracted from SIO Ethernet 2*RJ45 Gigabit network interface Intel I211 network chip | support adaptive 10/100/1000Mbps and WOL function Graphic Control Intel HD Graphics Display Interface VGA:1*DB15 | Maximum resolution:2560×1600@60HZ HDMI:1*DP | Maximum resolution: 1920×1200@60HZ LVDS:1*Dual channel | Maximum resolution: 1920×1200@60HZ Support VGA+LVDS、VGA+HDMI、HDMI+LVDS Independent dual displays SATA Interface 1*SATA3.0, 1*MSATA USB Interface 2*USB3.0(USB1 support USB3.0 USB2 suppoort USB2.0),2*USB2.0 1*2*5Pin 2.0mm( can transer 2*USB2.0) Serial Port 1*2×5 Pin 2.0mm contact pin（COM1_2） 1*2×20 Pin 2.0mm contact pin（COM3_6） COM1-COM6 can transfer to DB9, COM1 upport RS422/RS485 COM1 COM2 extracted from SIO, COM3_6 extracted from F81216AD Audio Realtek ALC662 audio control chip | support Two-channel stereo 1*Green Line_out |1* Pink MIC_in 1*2*5Pin2.54mm | support Mic_in、Line_out GPIO 8-bit programmable digital I/O pin Expansion Slots 2*Mini PCIE (MINI_PCIE1_SSD supports MSATA ) (MINI_PCIE2_3G supports WIFI/3G/4G with SIM card slot) 1*2*20Pin (LPC、PCIE*1/USB) Watchdog 255-level timer causes a reset when overflowed Power Requirement JACK/2Pin Work Temperature -20℃~70℃ (SSD) Storage Temperature -40～85℃ Relative Humidity 5%～95% non-condensation OS Windows 7, winwows8.1,windows10,LINUX Size 115mm*165mm Product Description Optional Version EP-4120-01 EP-4120 V1.1 Intel J1900，1×DDR3L SODIMM，1×VGA，1×HDMI，2×Intel I211 LAN，1×MINI PCIE，1×MSATA，1×SATA，1×USB3.0，7×USB2.0(4×Built In Pins+3×Rear IO) ，6×COM(COM1 support RS232/RS422/RS485)，8×GPIO EP-4120-02 EP-4120 V1.1 Intel J1900，1×DDR3L SODIMM，1×VGA，1×HDMI，2×Intel I211 LAN，1×MINI PCIE，1×MSATA，1×SATA，1×USB3.0，7×USB2.0(4×Built in Pins+3×Rear IO) ，6×COM(COM1 support RS232/RS422/RS485)，1×LVDS，8×GPIO EP-4120-03 EP-4120 V1.1 Intel J1800，1×DDR3L SODIMM，1×VGA，1×HDMI，2×Intel I211 LAN，1×MINI PCIE，1×MSATA，1×SATA，1×USB3.0，7×USB2.0(4×Built In Pins+3×Rear IO) ，6×COM(COM1 support RS232/RS422/RS485)，8×GPIO EP-4120-08 EP-4120 V1.1 Intel J1900，1×DDR3L SODIMM，1×VGA，1×HDMI，2×Intel I211 LAN，1×MINI PCIE，1×MSATA，1×SATA，1×USB3.0，7×USB2.0(4×Built In Pins+3×Rear IO) ，6×COM(COM1 support RS232/RS422/RS485)，8×GPIO,1×JCON EP-4120-09 EP-4120 V1.1 Intel J1800，1×DDR3L SODIMM，1×VGA，1×HDMI，2×Intel I211 LAN，1×MINI PCIE，1×MSATA，1×SATA，1×USB3.0，7×USB2.0(4×Built In Pins+3×Rear IO) ，6×COM(COM1 support RS232/RS422/RS485)，8×GPIO,1×JCON Packing&Shipping
