Description

Technical Specifications  Technical Specifications Cable gland Type of sealing Sealing ring For ATEX classification, Ex-zone dust None For ATEX classification, Ex-zone gas None Degree of protection (IP rating) IP68 Material Plastic Thread type Metric Colour Black Model Straight Material qualifier Polyamide (PA) Surface protection Untreated Nominal thread size metric/PG 16 Thread length 8 mm Pitch thread 1.5 mm Suitable for cable outer diameter 5 – 10 mm Shock resistant No Working temperature -40 – 100 °C RAL number 9005 Hexagon angular dimension 19 mm Wrench width 19 mm With strain relief Yes Halogen free No Glass fibre reinforced No Separable (split) screw gland No Flat cable sealing No Explosion-tested version No Bend radius protection/trumpet flare No Locknut included No EMC-version No Screened No Multi cable sealing No Snapping in opening No For armoured cable No · Technical Data Sheet – Click to Download
