Description

Technical Specifications  Technical Specifications Cable gland Type of sealing Sealing ring Material Plastic Colour Grey For ATEX classification, Ex-zone gas None For ATEX classification, Ex-zone dust None Degree of protection (IP rating) IP68 Thread type Metric Model Straight Material qualifier Polyamide (PA) Surface protection Untreated Nominal thread size metric/PG 25 Hexagon angular dimension 30 mm Pitch thread 1.5 mm Bend radius protection/trumpet flare No Screened No Glass fibre reinforced No Working temperature -40 – 100 °C Suitable for cable outer diameter 10 – 17 mm Wrench width 30 mm RAL number 7005 Thread length 10 mm Locknut included No Shock resistant No With strain relief Yes Explosion-tested version No Separable (split) screw gland No Flat cable sealing No Multi cable sealing No EMC-version No For armoured cable No Snapping in opening No Halogen free No · Technical Data Sheet – Click to Download
