Contactor 4Pole Screw Clamp 230V 50/60Hz
£36.55 Incl. VAT
TeSys K contactor, 4 poles (4NO), for non-inductive load control applications up to 20A/690V AC-1. It provides a 230V 50/60Hz AC coil, without built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). · · · TeSys K contactor, 4 poles (4NO), for non-inductive load control applications up to 20A/690V AC-1. · · Number of Poles: 4P · · It provides a 230V 50/60Hz AC coil, without built-in auxiliary contact, connection by screw clamp terminals. · · For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. · · Very compact (45mm width), DIN-rail mounting or screw fixing. · · Depth: 57mm · · Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Out of stock
Description
Technical Specifications Technical Specifications Power contactor, AC switching Number of normally closed contacts as main contact 0 Number of auxiliary contacts as normally open contact 0 Number of main contacts as normally open contact 4 Rated operation current Ie at AC-1, 400 V 20 A Rated control supply voltage at AC 50 Hz 230 – 230 V Number of auxiliary contacts as normally closed contact 0 Rated control supply voltage at AC 60 Hz 230 – 230 V Modular version No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2187998
