CR-M024DC2L Pluggable interface relay 2c/o – A1-A2=24VDC – 250V/12A – LED

The CR-M024DC2L pluggable interface relay is from the CR-M (miniature) relay range. This relay operates with a 24 V DC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 12 A. The relay has an integrated blue test button for manual actuation and locking of the output contacts and an integrated LED. Standard sockets, logic sockets, pluggable function modules, holder and marker are available as accessories. · · · IP40 · · Plate rail mounting · · It provides a 24V DC control circuit with no inrush consumption, connection by screw clamp terminals. · · For high operating rates until 180 cycles/min and ambient temperature -25/+50°C, it procures high reliability and durability. · · Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. · · Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium product (RoHS/REACh).
