ABB CR-M110AC4L Pluggable interface relay 4c/o - A1-A2=110VAC - 250V/6A - LED
ABB CR-M110AC4L Pluggable interface relay 4c/o - A1-A2=110VAC - 250V/6A - LED
ABB CR-M110AC4L Pluggable interface relay 4c/o - A1-A2=110VAC - 250V/6A - LED - Image 2
ABB CR-M110AC4L Pluggable interface relay 4c/o - A1-A2=110VAC - 250V/6A - LED - Image 3
ABB CR-M110AC4L Pluggable interface relay 4c/o - A1-A2=110VAC - 250V/6A - LED - Image 4

ABB CR-M110AC4L Pluggable interface relay 4c/o – A1-A2=110VAC – 250V/6A – LED

£9.60 Incl. VAT

The CR-M110AC4L Pluggable Interface Relay Is From The CR-M (Miniature) Relay Range. This Relay Operates With A 110 V AC Rated Control Supply Voltage And Has A 4 C/O (SPDT) Output With Contacts Rated At 250 V / 6 A. The Relay Has An Integrated Orange Test Button For Manual Actuation And Locking Of The Output Contacts And An Integrated LED. Standard Sockets, Logic Sockets, Pluggable Function Modules, Holder And Marker Are Available As Accessories. · · · Pluggable Interface Relay

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 1SVR405613R7100 Categories: , , Product Code: 2500247151

Description

Technical Specifications  Technical Specifications Switching relay Width 21.2 mm Nominal current 6 A Height 35.6 mm Number of contacts as change-over contact 4 Number of contacts as normally open contact 0.00 Depth 27.5 mm Number of contacts as normally closed contact 0.00 Rated control supply voltage at DC – – – V Rated control supply voltage at AC 50 Hz 110 – 110 V Rated control supply voltage at AC 60 Hz 110 – 110 V With forced-guided contacts No With detachable clamps No Complete with socket No With LED indication Yes · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
