Crabtree 16A 30mA SPswN C Curve 6kA Type A Miniature RCBO
£38.86 Incl. VAT
· · Single module, Miniature RCBO · · 16A C curve (MCB), 30mA Type A (RCD) · · Single pole with switched neutral · · Plug in
Description
Technical Specifications Technical Specifications Earth leakage circuit breaker/RCBO Recess depth 73 mm Rated current 16 A Rated voltage 230 V Width in number of modular spacings 1 Current limiting class 3 Rated insulation voltage Ui 400 V Rated short-circuit breaking capacity Icn according to EN 61009-1 6 kA Rated fault current 0.03 A Over voltage category 3 Number of poles (total) 2 Number of protected poles 1 Connectable conductor cross section solid-core 0.75 – 16 mm² Rated impulse-withstand voltage (Uimp) 4 kV Connectable conductor cross section multi-wired 0.75 – 16 mm² Ambient temperature during operating -5 – 40 °C Anti-nuisance tripping version No Concurrently switching N-neutral Yes With interlocking device No
