Crabtree 40A 30mA SPswN C Curve 6kA Type A Miniature RCBO
Crabtree 40A 30mA SPswN C Curve 6kA Type A Miniature RCBO
Crabtree 40A 30mA SPswN C Curve 6kA Type A Miniature RCBO - Image 2

Crabtree 40A 30mA SPswN C Curve 6kA Type A Miniature RCBO

£38.86 Incl. VAT

Crabtree Starbreaker Miniature RCBO is a plug-in MCB sized, for use in domestic household premises and similar installations. Starbreaker miniature RCBO brings higher levels of safety to an electrical installation and its users because it includes switche · · · Single module, Miniature RCBO · · 40A C curve (MCB), 30mA Type A (RCD) · · Single pole with switched neutral · · Plug in · · RCD Type A – Pure AC and pulsating DC sensitivity · · BS 7671 IET Wiring Regulations · · Switched neutral built in as standard, fully isolates faults · · Instant guaranteed plug in connections · · Fully insulated busbar with permanent shields · · Neutral conductor switching

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 61/CM4030 Categories: , , Brand: Product Code: 2501074755

Description

Technical Specifications  Technical Specifications Earth leakage circuit breaker/RCBO Rated voltage 230 V Rated current 40 A Recess depth 73 mm Over voltage category 3 Number of poles (total) 2 Rated impulse-withstand voltage (Uimp) 4 kV Width in number of modular spacings 1 Current limiting class 3 Number of protected poles 1 Rated insulation voltage Ui 400 V Rated fault current 0.03 A Rated short-circuit breaking capacity Icn according to EN 61009-1 6 kA Connectable conductor cross section solid-core 0.75 – 16 mm² Connectable conductor cross section multi-wired 0.75 – 16 mm² Ambient temperature during operating -5 – 40 °C Concurrently switching N-neutral Yes Anti-nuisance tripping version No With interlocking device No
