Crabtree Rockergrid Grid Switch 2 Way c/w Key 20A White
Crabtree Rockergrid Grid Switch 2 Way c/w Key 20A White
Crabtree Rockergrid Grid Switch 2 Way c/w Key 20A White - Image 2
Crabtree Rockergrid Grid Switch 2 Way c/w Key 20A White - Image 3

Crabtree Rockergrid Grid Switch 2 Way c/w Key 20A White

£10.02 Incl. VAT

Crabtree Rockergrid provides the design versatility of a modular switch range whilst incorporating the patented and consistent styling with many benefits. The range covers both flush and surface assemblies available in a number of finishes. · · · Fully Rated for Fluorescent Loads – Current Rating: 20 Amp · · Screw Fixed 1 Way · · Single Pole · · Terminal capacity: 3 x 2.5mm2 or 2 x 4mm2 · · Manufactured according to BS EN 60669-1

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 4551 Categories: , , Brand: Part Number: 2500137785

Description

Technical Specifications  Technical Specifications Switch Colour of rocker/switch operator White Method of operation Key Nominal voltage 250 V Minimum depth of back box 25 mm Height of device 55.5 mm Switching current for fluorescent lamps 20 AX Number of rockers/gangs 0 Push button switch No Feedback-signal contact No Width of device 25 mm Recess depth 20.5 mm Number of module spaces (modular system) 1 Depth of device 25 mm Rated current 20 A Washing machine switch No With mounting plate No Halogen free Yes · Technical Data Sheet – Click to Download
