Dorman Smith MCB K Series Type B SP 6A 10Ka
£15.65 Incl. VAT
Miniature Circuit breakers are designed to be used with the Loadlimiter 63 SP&N and TP&N distribution board systems. · · · 1-pole MCB · · 10kA MCB 1-pole 6A B type · · 10kA rated to EN 60898 · · 15kA rated to EN 60947 · · Contact position indicator · · Maximum cable termination of 35mm²
Out of Stock
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) B Voltage type AC Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 15 kA Number of poles (total) 1 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 15 kA Rated current 6 A Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Frequency 50 – 60 Hz Rated voltage 400 V
