Dorman Smith MCB K Series Type C SP 63A 10Ka
Dorman Smith MCB K Series Type C SP 63A 10Ka
Dorman Smith MCB K Series Type C SP 63A 10Ka - Image 2
Dorman Smith MCB K Series Type C SP 63A 10Ka - Image 3
Dorman Smith MCB K Series Type C SP 63A 10Ka - Image 4

Dorman Smith MCB K Series Type C SP 63A 10Ka

£19.61 Incl. VAT

Miniature Circuit breakers are designed to be used with the Loadlimiter 63 SP&N and TP&N distribution board systems. · · · 1-pole MCB · · 10kA MCB 1-pole 63A C type · · 10kA rated to EN 60898 · · 15kA rated to EN 60947 · · Contact position indicator · · Maximum cable termination of 35mm²

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: K1PC63 Categories: , , Brand: Product Code: 2500328730

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) C Voltage type AC Rated current 63 A Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 15 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 15 kA Number of poles (total) 1 Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated voltage 400 V Frequency 50 – 60 Hz
