Eaton Bussmann 50A 80kA BS88 Fuse Link BAO 500V 21 x 87mm
Eaton Bussmann 50A 80kA BS88 Fuse Link BAO 500V 21 x 87mm
Eaton Bussmann 50A 80kA BS88 Fuse Link BAO 500V 21 x 87mm - Image 2

Eaton Bussmann 50A 80kA BS88 Fuse Link BAO 500V 21 x 87mm

Pack of 20

£141.86 Incl. VAT

An Fuse Link with offset bolted tags. The range of British standard Low Voltage Fuse Link size is A3, for protection of general industrial applications. · · · Good peak let-through current limitation · · 1: 1.6 Selective coordinate ratio between ‘minor’ and ‘major’ fuse · · Power loss values well within the limits of IEC 60269 · · Recyclable

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: BAO50 Categories: , Brand: Product Code: 2500012973

Description

Technical Specifications  Technical Specifications HRC fuse Colour code None Type of fuse status indicator None Fuse system according to IEC 60269 Fuse system E Utilization category gG (cable protection/equipment protection) Fuse construction type according to IEC 60269 A3 Mounting holes M5 Current type AC Rated current 50 A Breaking capacity 80 kA Rated voltage AC 500 V Centre-to-centre distance of connections 73.5 mm Power loss at rated current 4.9 W
