Eaton EAD06B MCB 1-Pole 6A Type B 6A 6kA - 17.5 x 80 x 75mm
Eaton EAD06B MCB 1-Pole 6A Type B 6A 6kA - 17.5 x 80 x 75mm
Eaton EAD06B MCB 1-Pole 6A Type B 6A 6kA - 17.5 x 80 x 75mm - Image 2

Eaton EAD06B MCB 1-Pole 6A Type B 6A 6kA – 17.5 x 80 x 75mm

£3.65 Incl. VAT

Single pole Type B MCB suitable for Eaton Single Phase Consumer Units · · · DIN rail mountable and suitable for use with both pin and comb type busbar systems · · Toggle position for positive contact indication · · Selectivity Class 3 · · Calibration temperature 40°C · · Suitable for use on 230/240 V, AC system and are calibrated for use at 40 °C · · Fitted with box clamp terminals suitable for use with cables up to 25 mm² · · Suitable for general, domestic and commercial installations having little or no switching surges

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EAD06B EATON DUPE Categories: , , Brand: Part Number: 2500315588

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) B Voltage type AC/DC Number of poles (total) 1 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Pollution degree 2 Current limiting class 3 Rated insulation voltage Ui 440 V Number of protected poles 1 Rated impulse-withstand voltage (Uimp) 4 kV Over voltage category 3 Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 0 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 0 kA Width in number of modular spacings 1 Rated voltage 230 V Rated current 6 A Recess depth 75.5 mm Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Explosion-proof No Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible No
