Eaton EAD16B_DUP MCB 1-Pole 16A Type B 6kA 17.5 x 80 x 75mm
£3.65 Incl. VAT
The Steeple 1-pole Curve-B miniature circuit breaker is DIN rail mountable and suitable for use with both pin and comb type bus bar systems. Suitable for general, domestic and commercial installations having little or no switching surges. Fitted with box clamp terminals suitable for use with cables up to 25 mm² · · · Toggle position for positive contact indication · · Selectivity class 3 · · Calibration temperature 40°C · · Suitable for use on 230/240 V AC systems
Out of stock
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Tripping characteristic (type/curve) B Voltage type AC/DC Recess depth 75.5 mm Rated current 16 A Rated voltage 230 V Number of poles (total) 1 Rated impulse-withstand voltage (Uimp) 4 kV Width in number of modular spacings 1 Number of protected poles 1 Pollution degree 2 Over voltage category 3 Current limiting class 3 Rated insulation voltage Ui 440 V Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 0 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 0 kA Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Explosion-proof No Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible No
