Eaton EAD50B MCB 1-Pole 50A Type B 6kA – 17.5 x 80 x 75mm
£3.78 Incl. VAT
Single pole Type B MCB suitable for Eaton Single Phase Consumer Units · · · DIN rail mountable · · Toggle position for positive contact indication · · Selectivity Class 3 · · Calibration temperature 40°C · · Suitable for use with both pin and comb type bus bar systems · · Suitable for use on 230/240 V · · Fitted with box clamp terminals suitable for use with cables up to 25 mm² · · Suitable for general, domestic and commercial installations having little or no switching surges
Out of stock
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Degree of protection (IP rating) IP20 Voltage type AC/DC Tripping characteristic (type/curve) B Rated voltage 230 V Rated current 50 A Width in number of modular spacings 1 Rated insulation voltage Ui 440 V Current limiting class 3 Over voltage category 3 Pollution degree 2 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Recess depth 75.5 mm Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 0 kA Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 0 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Number of poles (total) 1 Rated impulse-withstand voltage (Uimp) 4 kV Number of protected poles 1 Frequency 50 – 60 Hz Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 75 °C Explosion-proof No Concurrently switching N-neutral No Additional equipment possible No Flush-mounted installation No · Technical Data Sheet – Click to Download
